상세 정보 |
|||
| 커넥터 유형: | Deutsch J1939 HD-16-9-1939S-P080 HD-10-9-1939P-P080 | 핀 수: | 2 핀 |
|---|---|---|---|
| 와이어 유형: | UL 1007 18# 및 16# | 연락처 보유: | 20 파운드 |
| 크림프 인장: | > 20 파운드 (18#),> 25 lbs (16#) | 작동 온도: | -40 +~ +125 ℃ |
| 진동 저항: | 20g은 2 시간 동안 10-2000Hz에서 | IP 등급: | IP68 |
| 방수 깊이: | 24 시간 동안 1.2 미터 | 터미널 유형: | 1060-16-0122 |
| 실패 모델: | 와이어 손상, 그로 메트 고장 | 재료: | 실리콘 고무 밀봉, 열가소성 |
| 커넥터 시리즈: | EDG-HD | 색상 옵션: | 빨갛고 검고 푸르고 녹색입니다 |
| 사용자 정의 길이: | 예 | ||
| 강조하다: | 16pin OBDII Passthru Cable,IP68 Rating Automotive Wiring Harness,Power Break Out Diagnostic Connector Cable |
||
제품 설명
The EDG-HD series is an environmentally sealed silicone rubber thermoplastic cylindrical connector designed for fast, easy, trouble-free assembly in heavy-duty diagnostic applications including trucks, buses, cross-country vehicles, cranes, and forklifts. When mated, the contacts are protected from water, dust, oils, fuel, road salt, grease, mud, and other contaminants.
- Operating temperature range: -40℃ to +125℃ (no cracking, chipping, or leaking after 20 test cycles)
- Withstands 20 G's sinusoidal vibration at 10-2000Hz for 2 hours in three mutually perpendicular planes with no mechanical damage
- IP68 rated - waterproof with immersion under 1.2 meters of water for 24 hours
| Terminal Type | Wire Type | Contact Retention | Ref Crimp Tensile | Failure Model |
|---|---|---|---|---|
| 1060-16-0122 | UL 1007 18# | 20 LBS | >20 LBS | Wire damage |
| 1060-16-0122 | UL 1007 16# | 20 LBS | >25 LBS | Grommet broken |
| Terminal Type | Wire Type | Contact Retention | Ref Crimp Tensile | Failure Model |
|---|---|---|---|---|
| 1060-16-0122 | UL 1007 18# | 20 LBS | >20 LBS | Wire damage |
| 1060-16-0122 | UL 1007 16# | 20 LBS | >25 LBS | Grommet broken |
Packaging can be customized to client specifications. Standard lead times:
| Quantity (PCS) | 1 - 1000 | 1001 - 5000 | >5000 | Mold/Tooling |
|---|---|---|---|---|
| Est. Time (Days) | 20 | 25 | To be negotiated | 30 days more |
International shipping available via DHL, UPS, FedEx, TNT, ARAMEX, and EMS. Options for air, sea, or other shipping methods.
Q: Can you help with design?
A: Yes, we are an ODM/OEM company specializing in wire harness and cable assembly since 1999.
Q: When will you start the design process?
A: We provide initial sketches for discussion. After order confirmation, we create detailed drawings for client approval.
Q: How do you handle quality issues?
A: Our quality team responds within 72 hours to resolve any issues, as we prioritize long-term customer relationships.
Q: Do you have standard products to reduce lead time?
A: Yes, we maintain over 1000 molds and 5000+ wire harness products developed over 20+ years of experience.
